FULLY AUTOMATE YOUR  SHOP

WITH

ER SERIES

 INDUSTRIAL GRADE CNC ROUTERS

RAPID MACHINING FOR:

​

PROTOTYPING * WOODWORKING * SIGNAGE

​

* WOOD

* PLASTICS

* NON-FERROUS METALS

​

WITH POWER AND ACCURACY

Design it!

Make it!

Feedrate CNC



ER SERIES MODELS

ER-B
ER-HB
ER-BTC
ER-QTC
ER-OATC
ER-XL
ER-XL

FEATURES AT A GLANCE


16 POSITION ORBITAL - ATC

16 Position Tool Changer

Full Size Control Cabinet

  • Fully ventilated for maximum cooling

  • Easy access to all control components


16 POSITION ORBITAL - ATC

HSD ES951 e-core SERIES SMART SPINDLE


Industrial Grade Syntec Controller​​


Manual Pulse Generator


Material Load Assist Rollers


Multi-Zone Vaccum Table Top


1

2

5

6

Automatic Axis Lubrication System


Tool Change Post


  • Precision Linear Rails and Bearings

  • Inverted Helical Rack and Pinion


*Optional T-Slots

Vaccum/T-Slot Hold-down Combination



FEATURES & OPTIONS

ES951 E-CORE SMART SPINDLE

12.8 HP HSD SPINDLE

The 12.8 HP HSD ES951 e-core SMART SPINDLE is the most powerful in its class and is next-gen spindle technology.


HIWIN LINEAR GUIDEWAYS

25mm linear rails and bearings with internally lubricated, re-circulating ball bearings within the bearing block.


TOOL MEASURE SWITCH

Quick and accurate automatic tool measure switch


YASKAWA SIGMA 7 SERVO SYSTEM

Yaskawa Sigma 7 Servo drives and motors provide the highest speed and cutting accuracy in the industry. Delivering your cut part within +/-.0002"


RIGID FRAME

All of our CNC Routers come standard with a fully steel welded frame, providing you
with maximum rigidity.


MATERIAL LOAD ASSIST & POSITIONING

Material load assist rollers and pneumatic material positioning stops.


INDUSTRIAL GRADE SYNTEC CONTROLLER

Syntec controllers provide ease of use, flexibility, reliability and all of the features of an industrial controller.


16 POSITION AUTO TOOL CHANGER

Capable of up to 16 tools within the rotary or orbital tool changer.

*Linear tool changer also available

​


AUTO AXIS LUBRICATION

Automatic X/Y/Z axis lubrication system.

T-Slot Tabletop

T-Slot Workpiece Holddown

drill bank.jpg

HSD DRILL BANK

9-Tool HSD Drill Bank

Multi-zone Vacuum Tabletop

Multiple Zone Vacuum hold-down table top

9c3925_ecd250b71f2447dfb84316147eafeebb_

2200 LB CAPACITY AUTOMATIC LIFT

Height Sensor driven pneumatic lift for material entry feed.

MPG

Manual pulse generator for manual positioning of X/Y/Z axis.


AUTOMATIC MATERIAL UNLOAD CONVEYOR

Automatic finish part unload conveyor.








VACUUM PUMP

REGENERATIVE BLOWER

DUST COLLECTOR

Up to 14.7 hp, 225 cfm (air flow) and 27 hg"(vacuum capacity). For lower air flow/higher vacuum force applications.

Up to 16.8 hp, 644 cfm (air flow) and 13.5 hg"(vacuum capacity). For higher air flow/lower vacuum force applications.

Height Sensor driven pneumatic lift for material entry feed.



1-DESIGN YOUR PART/S


OR

UPLOAD

USB

2-SEND DESIGN TO CNC ROUTER

3-LOAD YOUR MATERIALS

CNC ROUTER

HOW

IT WORKS

 After initial setup, cutting your part is a 3-step process.

Design your part/s using CNC Programming software OR Design right at the CNC Router.

Send your finished part design to the CNC Router via Upload or USB Drive.



If you designed at he CNC Router, simply select your part.

Load your material onto the table and start the cut cycle.

SAVE

TIME - MONEY - MANPOWER

ER-AL

​

FEATURING

  • AUTO LABLEING

  • AUTO LOADING

  • AUTO MACHINING

  • AUTO OFF-LOADING
